As you know, within Civil 3D there are many reporting methods for creating tables and exporting reports. Within your Civil 3D files there is an abundance of information. Report and Share Data using Project Explorer

Objects within your civil model that are considered to be in an abnormal state.īecause Project Explorer always displays live information from the civil model, you can monitor how each violation is impacted by every design decision you make.

Areas of your design that may not fully meet your design goals.Violation reporting quickly draws your attention to: Validate Your Design using Project Explorerĭynamic violation reporting is an important feature within the Project Explorer window. The options within Project Explorer for pipe networks are never-ending! You can easily switch between pipe runs, edit multiple lines, SWAP MULTIPLE parts and make global changes that you’ve always wanted to make, but never had the option to.Īnd new in Civil 3D 2022 Project Explorer, you can now view and edit PRESSURE NETWORKS, where in the past version you were only able to edit gravity networks. And being able to make edits, perform changes to geometry or styles without jumping all over the place in your model settings is extremely helpful. If you use dual monitors, I’d consider keeping Project Explorer open on your second monitor while you work in Civil 3D.īeing able to see all alignments, profiles, and sections in one area, and to be able to switch between features is key to streamlining workflows.

#Civil 3d 2020 update#

Therefore, if something is modified or added to the Civil 3D model, the content in Project Explorer will update automatically.

#Civil 3d 2020 series#

Now, you can view and edit Civil 3D designs in a tabbed series of object lists, profile and section views, parameter lists, and many other design review tools.Īll information displayed in the Project Explorer window is live geometric project data from the Civil 3D model. Typically, to manage project and drawing objects, users would use the Toolspace Prospector tab in Civil 3D. Discover and evaluate design criteria to help meet design standards.Simplifies project data navigation, review, and editing of your Civil 3D models.Civil 3D users now have a more efficient way to access, interact, and share the staggering array of design information that is in a Civil 3D model. Project Explorer provides users with an easy-to-use Civil 3D design model review tool and user-configurable report generator. Once installed, it can be found on the Add-ins tab of the ribbon. It installs for Civil 3D 2020, 2021 and now 2022. This came out as an add-on for Civil 3D sometime last year in one of the products final updates.

However, we can no longer just look at what’s new in our hero product, but all other complementary products as well, so I will briefly mention a few of those. There are a couple of things in the upcoming release of Civil 3D 2022 that I think could be real game changers and I’m happy to share them with you. Yes, there were a lot of little things, and some nice additional, but nothing that made you go “WOW!” Until now… In the past few versions of Civil 3D, there haven’t really been any changes that I think could really change the game and give your productivity a big boost.
